Coordinate Verification System for Borehead Inspection

Customer: A leading supplier of heavy machinery, rock tools, and digital solutions for the mining and infrastructure industries.

Project: Automated coordinate verification system for precision inspection of rock drill bits.

Product Description

Syntronic developed an advanced coordinate measurement system to automate production verification of rock drill bits. Utilizing high-precision blue laser scanning technology, the solution accurately measures critical borehead features to ensure every component meets stringent manufacturing requirements before proceeding through production.

Designed for continuous operation in a demanding manufacturing environment, the system delivers fast, reliable, and repeatable measurements while supporting high production throughput. By automating the inspection process, the solution improves quality assurance, reduces manual measurement efforts, and increases confidence in product consistency.

Scope

The project included the design and development of a fully automated metrology solution for inspecting rock drill bits using advanced blue laser scanning technology. The system precisely scans each component to identify hole positions and orientations, achieving measurement accuracy of ±0.03 mm.

Custom-developed software processes the measurement data in real time, verifying that every drill bit complies with tight dimensional tolerances and manufacturing specifications. The inspection system is fully integrated into the production line, enabling automatic part handling, measurement, and data collection without interrupting production flow.

The complete solution provides manufacturers with comprehensive production verification while supporting efficient, high-volume manufacturing and consistent product quality.

Results

The coordinate measurement system delivers fast and highly accurate inspection of rock drill bits, ensuring critical borehead features meet demanding quality requirements before the products leave production.

By combining precision blue laser scanning with automated inspection and seamless production integration, Syntronic delivered a robust metrology solution that improves process control, enhances product quality, and reduces the need for manual inspection. The system has been successfully installed and is operating in a production environment, supporting efficient manufacturing and consistent quality assurance.
